Front & Back Labeling Machine for Wine Bottles
Front & Back Labeling Machine for Wine Bottles
Front & Back Labeling Machine for Wine Bottles
1 / 3
Front & Back Labeling Machine for Wine Bottles
Front & Back Labeling Machine for Wine Bottles
Front & Back Labeling Machine for Wine Bottles

Front & Back Labeling Machine for Wine Bottles

Customization: Available
After-sales Service: 1 Year Guaranteed, Full-Life Service
Warranty: 1 Year
Send Inquiry

Product Description

Basic Info.

Model NO.
DWTB90/160
Automatic Grade
Automatic
Application
Cosmetics, Drinks, Cleaning, Detergent, Skin Care Products, Hair Care Products, Oil, Seasoning, Dairy Products
Type
Automatic Labeling Machine
Driven Type
Electric
Classification
Automatic Vertical Round Bottle Labeling Machine
Transport Package
Wooden Box
Specification
CE
Production Capacity
300

Product Description

Orientational Vertical Labeling Machine for Conical Containers
Model: DWTB90/160/200

Vertical Labeling Machine

The labeling machine is for different shape containers. When labeling, the bottle will automatically rotate to allow the labeling device to apply the pressure for labeling. It's suitable for medicine, food, beverage and chemical industries.

It can be used for plastic, glass, metal and other round containers/ bottles. Replacements of a few parts, it also can be used for square bottles.

Key Features
✓ Simple and compact design for space efficiency.
✓ PLC control System with Feather touch Keyboard and LCD display.
✓ Memory storage for up to 16 different programs for various bottle types.
✓ Precise label release and fixing mechanism.
✓ Advanced motor drives (Sunx or Servo) per requirements.
✓ High sensitivity, stability, and anti-interference technical characteristics.

Technical Specification

Labeling Speed0~100 bottles/minute
Precision±1mm
Inner Diameter Rollφ76mm
Outer Diameter Rollφ300mm
Products Diameterφ12mm~100mm
Label Width10mm~1600mm
Label Length15mm~350mm
Conveyor DirectionL→R / R→L
Electrical Requirements220V 50HZ
Power700W
Dimension1600mm×1100mm×1300mm
Note: Speed is determined by label length. Special needs available upon request.

Product Visuals & Facilities

Labeling Machine Detail
Certification
Factory Overview
Production Line

Our Packaging Solutions

  • 01. Unscrambler for various packing lines
  • 02. Filling Machine
  • 03. Capping Machine
  • 04. Sealing Machine
  • 05. Labelling Machine
  • 06. Carton Packing Line
Frequently Asked Questions
What types of containers can this machine label?
It is designed for various round containers made of plastic, glass, or metal. With minor part replacements, it can also accommodate square bottles.
How precise is the labeling process?
The machine offers high precision with a tolerance of ±1mm, ensuring consistent placement for professional packaging.
Can the machine handle different bottle sizes without complex reconfiguration?
Yes, the PLC system can store up to 16 different programs, making it easy to switch between different bottle settings quickly.
Does the machine support batch coding?
On-line batch coding is an optional feature that can be integrated into the machine according to your specific production requirements.
What industries is this equipment best suited for?
It is ideal for the cosmetics, beverage, food, medical, and chemical industries, handling everything from skin care products to seasoning and detergents.
What is the maximum labeling speed?
The machine can reach speeds of up to 100 bottles per minute, depending on the specific length of the labels being used.
