Compact Single-Arm Hydraulic Press for Punching and Cutting

I. Overview of Machine Performance and Structure

• Single-Arm Frame Structure: Consists of a worktable, main cylinder, hydraulic power system, and electrical control system. The whole frame is welded with high-quality Q235 steel plates and subjected to aging treatment to eliminate welding stress.
• Single-Piston Cylinder: Pressing tonnage is achieved by a single piston cylinder made of 45# forged steel. The piston rod surface is medium-frequency quenched for durability. Key components utilize high-quality sealing rings.

II. Advanced Hydraulic System

• Hydraulic components are securely installed inside the machine frame for protection.
• The power unit includes an oil tank (steel plate welded, fully enclosed), high-pressure pump, motor, and directional control valves.
• Leak-free performance with flanged pipeline connections and anti-vibration measures.

III. Electrical Control System

• Electrical cabinet equipped with air circuit breakers and relays for stable operation.
• Integrated program interlocking for signals, limit positions, and pressure actions.
• Centralized control panel with ergonomic operation buttons and selector switches.
